The SMIS spectromicroscopy beamline aims to deliver high brilliance infrared radiation in the 2.5-100 microns spectral range. The synchrotron beam is split to operate two systems working in parallel. The beamline is dedicated to microscopic analysis of a variety of samples, spanning from polymer films and multilayers, minerals and other geological materials, biological and biomedical samples, to archaeology.
An ensemble of experimental cells are provided and adapted to accommodate various needs allowing experiments at various temperature and pressure conditions, under mechanical stress, etc. Besides working with commercially available equipment adapted to the synchrotron source, the SMIS beamline is a world leading facility in custom built IR instrumentation.
Technical data
Energy range
2 μm – 50 μm / 5000 cm-1 – 200 cm-1
Energy Resolution
0.1 cm-1 / 0.012 meV
Source
Edge and Bending Magnet Radiation - 78 mrad Horizontal × 20 mrad Vertical extraction
Flux @ first optical element
1.86×1014 Phot/s/0.1%bw @ 10 µm for 500 mA stored current
Optics
Combination of flat and toroid mirrors. The synchrotron beam is divided to feed two IR interferometers at the same time
Sample Environments
Single point microscopy
Time resolved, high spatial resolution microscopy (rapid scan and Step/Scan)
Single point raster mapping
ATR microscopy in inverted geometry
Very high sensitivity ATR spectroscopy (~70 ATR bounces)
2D IR imaging (under commissioning)
nanoIR techniques: sSNOM and phototermal AFM-IR (under commissioning)
Raman microscopy (off line)
Müller polarimetry (SR adaptation in progress, available with thermal source)
ATR and grazing incidence objectives
Diamond anvil cells: low (0.5-5 GPa) and moderately high (<40GPa) pressure
Cooling and heating sample stages (Linkam)
LHe flow cryostat (Oxford Microstat)
Beam size at sample
10×10 μm2 , or 20×20 μm2
Flux on sample
About 4.8×1013 Phot/s/0.1%bw at the entrance of the interferometer
Detectors
small area MCT (Mercury Cadmium Telluride), LHe cooled CuGe, InSb
Polarization
Both linearly (bending magnet emission) and radially polarized (edge radiation)
Scientific opportunities
|
Soft matter |
Microscopic Analysis of inclusions in polymers; polymer interfaces; chemical imaging of components and crystallinity;deformation under stretching;Chemical composition changes with temperature |
|---|---|
|
Geology |
Identification of inclusions in minerals; Chemical imaging of inclusions constituents; Interface studies, grain boundaries between minerals; archaeological minerals; Study of water recirculation in deep earth mantle; Deformation and chemical composition changes of minerals under high pressure |
|
Biology, Biomedical |
Individual cells study, Imaging biochemical compositon inside individual cells: Apoptosis et Necrosis; Tumoral cells; Study of human tissues: hair, skin, bone, brain... ; bacterial identification. |
|
Archeology |
Analysis of ancient mummies, ancient cosmetics; analysis of traces of paint composition. |
|
Thin Films |
Analysis and chemical imaging of thin films, protection layers |
|
Applied Research |
Analysis and expertise of various applied problems in a short time scale. |
Desription of experimental capabilities at the SMIS beamline both with synchrotron beam and off line instruments.
Point-to-point IR spectromicroscopy
Continuum XL microscope / Thermo Nicolet 6700 bench
| Location / branch | SMIS 1 |
| Spectral range | MCT/A detector, 650 - 6000 cm-1 |
| Spectral resolution | 0.125 - 32 cm-1 |
| Operation modes | Confocal dual aperture, single aperture, reflection and transmission geometry |
| Accessories | Linkam heating stage, high quality purge box, microfluidic devices, Thermo ATR accessory |
| Objectives | 15x (0.58 NA), 32x (0.65 NA), 15x ATR ZnSe |
Continuum microscope / Thermo Nicolet 8700 bench
| Location / branch | SMIS 2 |
| Spectral range |
MCT/A detector, 650 - 6000 cm-1 InGaAs detector 2000 - 14000 cm-1 |
| Spectral resolution | 0.125 - 32 cm-1 |
| Operation modes | Confocal dual aperture, single aperture, reflection and transmission geometry |
| Accessories | Linkam heating stage, microfluidic devices, Thermo ATR accessory |
| Objectives | 15x (0.58 NA), 32x (0.65 NA), 15x ATR ZnSe |
The Thermo Nicolet 8700 bench is capable of time resolved studies in Rapid Scan and Step/Scan modes.
Nicplan microscope / Thermo Fischer iS50 bench
| Location / branch | SMIS 2 |
| Spectral range |
MCT/A detector, 650 - 6000 cm-1 Si Bolometer, 100 - 900 cm-1 |
| Spectral resolution | 0.125 - 32 cm-1 |
| Operation modes | Confocal dual aperture, single aperture, reflection and transmission geometry |
| Accessories | Linkam heating stage, microfluidic devices, Diamond Anvil Cells |
| Objectives | 15x (0.58 NA), 32x (0.65 NA), Bruker Grazing Incidence Objective |
Horizontal microscope / Thermo Fischer iS50 bench
| Location / branch | SMIS 2 |
| Spectral range |
MCT/A detector, 650 - 6000 cm-1 Si Bolometer, 100 - 900 cm-1 |
| Spectral resolution | 0.125 - 32 cm-1 |
| Operation modes | Reflection and transmission geometry |
| Accessories | Diamond Anvil Cells (DAC), DAC LHe flow cryostat (base T~15K), DAC heating accessory (T up to 700 Cº), custom user experiments |
| Objectives | 15x (0.5 NA) |
Anasys NanoIR 2-s microscope
| Location / branch | SMIS 3 |
| Spectral range |
MCT/A detector, 650 - 6000 cm-1 |
| Spectral resolution | 2 - 32 cm-1 |
| Operation modes | AFM-IR (photothermal) and scattering SNOM spectromicroscopy |
| Accessories | 400 mW CO2 laser |
